SCHRADER INTERCHANGE PNEUMATIC QUICK DISCONNECTS
Shrader Interchange - SHD & TL Series
ZSi-Foster SHD & TL Series couplers are engineered for quick coupling and uncoupling.
|SHD and TL Series|
|Temp Range:||-40° to +250°F||• Engineered for speedy coupling and uncoupling. To lock - push in; To unlock - rotate sleeve 1⁄8 turn.
• Designed to protect against accidental uncoupling. A variety of types and sizes are available to meet specific needs.
• Standard Twist-Lock couplings are ideal for low to medium air flows, such as air tools.
|Vacuum Service:||27" Hg|
|Rated Pressure:||300 PSIG|
|Operation: Automatic Push to Connect; Twist-to-release|
|Materials: Aluminum bodies and zinc plated steel sleeves. Buna-N seals. Brass adapters|
