Page 9 - ZSi-Foster Cut Strut
P. 9
W100 Pre-Cut Channel
5
7
12 Gauge - 1 ⁄8" x 2 ⁄16" (41mm x 62mm)
7
5
W100: 1 ⁄8" x 2 ⁄16" (41mm x 62mm) - Solid Channel - Pre-Cut Lengths
Pre-Cut
Length
7
W100 - 1 ⁄8" x 2 ⁄16" - 12 Gauge Solid Channel
5
Pre-Cut Length Steel - PG ST304 ST316
6" (15.2cm) W100PG6IN W100ST3046IN W100ST3166IN
12" (0.31m) W100PG12IN W100ST30412IN W100ST31612IN
18" (0.45m) W100PG18IN W100ST30418IN W100ST31618IN
24" (0.61m) W100PG24IN W100ST30424IN W100ST31624IN
30" (0.76m) W100PG30IN W100ST30430IN W100ST31630IN
36" (0.91m) W100PG36IN W100ST30436IN W100ST31636IN
42" (1.07m) W100PG42IN W100ST30442IN W100ST31642IN
48" (1.22m) W100PG48IN W100ST30448IN W100ST31648IN
54" (1.37m) W100PG54IN W100ST30454IN W100ST31654IN
60" (1.52m) W100PG60IN W100ST30460IN W100ST31660IN
72" (1.83m) W100PG72IN W100ST30472IN W100ST31672IN
80" (2.03m) W100PG80IN W100ST30480IN W100ST31680IN
96" (2.44m) W100PG96IN W100ST30496IN W100ST31696IN
10' (3.05m) W100PG10 W100ST30410 W100ST31610
20' (6.10m) W100PG20 W100ST30420 W100ST31620
Note: Minimum order quantity is 100 pieces for any size under 10'.
W100SS: 1 ⁄8" x 2 ⁄16" (41mm x 62mm) - Channel with Short Slots - Pre-Cut Lengths
7
5
Channel With Short Slots
9 ⁄16" x 1- ⁄8" (14mm x 29mm) slots
1
are punched on 2" (51mm) centers. Pre-Cut
Length
5
7
W100SS - 1 ⁄8" x 2 ⁄16" - 12 Gauge - Channel with Short Slots
Pre-Cut Length Steel - PG ST304 ST316
6" (15.2cm) W100SSPG6IN W100SSST3046IN W100SSST3166IN
12" (0.31m) W100SSPG12IN W100SSST30412IN W100SSST31612IN
18" (0.45m) W100SSPG18IN W100SSST30418IN W100SSST31618IN
24" (0.61m) W100SSPG24IN W100SSST30424IN W100SSST31624IN
30" (0.76m) W100SSPG30IN W100SSST30430IN W100SSST31630IN
36" (0.91m) W100SSPG36IN W100SSST30436IN W100SSST31636IN
42" (1.07m) W100SSPG42IN W100SSST30442IN W100SSST31642IN
48" (1.22m) W100SSPG48IN W100SSST30448IN W100SSST31648IN
54" (1.37m) W100SSPG54IN W100SSST30454IN W100SSST31654IN
60" (1.52m) W100SSPG60IN W100SSST30460IN W100SSST31660IN
72" (1.83m) W100SSPG72IN W100SSST30472IN W100SSST31672IN
80" (2.03m) W100SSPG80IN W100SSST30480IN W100SSST31680IN
96" (2.44m) W100SSPG96IN W100SSST30496IN W100SSST31696IN
10' (3.05m) W100SSPG10 W100SSST30410 W100SSST31610
20' (6.10m) W100SSPG20 W100SSST30420 W100SSST31620
Note: Minimum order quantity is 100 pieces for any size under 10'.
Refer to Engineering Catalog for Beam & Column Loading Data of Solid, Back-to-Back, and Punched Channels
ZSi-Foster Cut Strut zsi-foster.com – 9 –
