Page 7 - ZSi-Foster Cut Strut
P. 7
W500 Pre-Cut Channel
13
1 ⁄8" x ⁄16" (41mm x 21mm) - 14 Gauge
5
13
5
W500: 1 ⁄8" x ⁄16" (41mm x 21mm) - Solid Channel - Pre-Cut Lengths
Pre-Cut
Length
5
W500 - 1 ⁄8" x ⁄16" - 14 Gauge - Solid Channel
13
Pre-Cut Length Steel - PG ST304 ST316
6" (15.2cm) W500PG6IN W500ST3046IN W500ST3166IN
12" (0.31m) W500PG12IN W500ST30412IN W500ST31612IN
18" (0.45m) W500PG18IN W500ST30418IN W500ST31618IN
24" (0.61m) W500PG24IN W500ST30424IN W500ST31624IN
30" (0.76m) W500PG30IN W500ST30430IN W500ST31630IN
36" (0.91m) W500PG36IN W500ST30436IN W500ST31636IN
42" (1.07m) W500PG42IN W500ST30442IN W500ST31642IN
48" (1.22m) W500PG48IN W500ST30448IN W500ST31648IN
54" (1.37m) W500PG54IN W500ST30454IN W500ST31654IN
60" (1.52m) W500PG60IN W500ST30460IN W500ST31660IN
72" (1.83m) W500PG72IN W500ST30472IN W500ST31672IN
80" (2.03m) W500PG80IN W500ST30480IN W500ST31680IN
96" (2.44m) W500PG96IN W500ST30496IN W500ST31696IN
10' (3.05m) W500PG10 W500ST30410 W500ST31610
20' (6.10m) W500PG20 W500ST30420 W500ST31620
Note: Minimum order quantity is 100 pieces for any size under 10'.
W500SS: 1 ⁄8" x ⁄16" (41mm x 21mm) - Channel with Short Slots - Pre-Cut Lengths
13
5
Channel With Short Slots
1
9 ⁄16" x 1- ⁄8" (14mm x 29mm) slots Pre-Cut
are punched on 2" (51mm) centers. Length
13
5
W500SS - 1 ⁄8" x ⁄16" - 14 Gauge - Channel with Short Slots
Pre-Cut Length Steel - PG ST304 ST316
6" (15.2cm) W500SSPG6IN W500SSST3046IN W500SSST3166IN
12" (0.31m) W500SSPG12IN W500SSST30412IN W500SSST31612IN
18" (0.45m) W500SSPG18IN W500SSST30418IN W500SSST31618IN
24" (0.61m) W500SSPG24IN W500SSST30424IN W500SSST31624IN
30" (0.76m) W500SSPG30IN W500SSST30430IN W500SSST31630IN
36" (0.91m) W500SSPG36IN W500SSST30436IN W500SSST31636IN
42" (1.07m) W500SSPG42IN W500SSST30442IN W500SSST31642IN
48" (1.22m) W500SSPG48IN W500SSST30448IN W500SSST31648IN
54" (1.37m) W500SSPG54IN W500SSST30454IN W500SSST31654IN
60" (1.52m) W500SSPG60IN W500SSST30460IN W500SSST31660IN
72" (1.83m) W500SSPG72IN W500SSST30472IN W500SSST31672IN
80" (2.03m) W500SSPG80IN W500SSST30480IN W500SSST31680IN
96" (2.44m) W500SSPG96IN W500SSST30496IN W500SSST31696IN
10' (3.05m) W500SSPG10 W500SSST30410 W500SSST31610
20' (6.10m) W500SSPG20 W500SSST30420 W500SSST31620
Note: Minimum order quantity is 100 pieces for any size under 10'.
Refer to Engineering Catalog for Beam & Column Loading Data of Solid, Back-to-Back, and Punched Channels
