Beta Clamps - Smoothie

BETA SMOOTHIE STANDARD SERIES BETA SMOOTHIE TWIN SERIES

Beta Smoothies are ideal for general-duty applications where there is a need to
reduce wear on hose connection caused by vibration and surge.
• Chamfered and smooth core protects hose cover and extends the life of the hose
• Uses Standard Beta hardware
• Reduces wear on hose connection caused by vibration and surge
INSTALLATION - Refer to pages 9 – 11 for complete installation guide.

Assembly Types Assembly Types

H C B R SI Z H C B R

SAE 100R1 SAE 100R1
Group Part No. Bolt Group Part No. Bolt
Hose Size Hose Size
S2004H 1 ⁄ 4" T2004H 1 ⁄ 4"
S2 1 ⁄ 4 – 20 x 1 ⁄ 8 T2 5 ⁄ 16 – 18 x 1 ⁄ 8
3
3
S2006H 3 ⁄ 8" T2006H 3 ⁄ 8"
S3008H 1 ⁄ 2" T3 T3008H 1 ⁄ 2" 5 ⁄ 16 – 18 x 1 ⁄ 4
3
S3 1 ⁄ 4 – 20 x 1 ⁄ 2
1
S3010H 5 ⁄ 8" T4010H 5 ⁄ 8"
T4 5 ⁄ 16 – 18 x 2
S4 S4012H 3 ⁄ 4" 1 ⁄ 4 – 20 x 1 ⁄ 4 T4012H 3 ⁄ 4"
3
S5 S5016H 1" 1 ⁄ 4 – 20 x 2 ⁄ 2 T5 T5016H 1" 5 ⁄ 16 – 18 x 2 3 ⁄ 8
1
*For additional sizes and stainless steel contact factory. *For additional sizes and stainless steel contact factory.
Note: Add Assembly type to Part No.- Example: S2004H provides the complete assembly as Note: Add Assembly type to Part No.- Example: T2004H provides the complete assembly as
shown shown
